huadaHAWKER霍克锂电池EV48-40

huadaHAWKER霍克锂电池EV48-40

北京
9999/ 件
1
1000
我要询价

huadaHAWKER霍克锂电池EV48-40huadaHAWKER霍克锂电池EV48-40huadaHAWKER霍克锂电池EV48-40huadaHAWKER霍克锂电池EV48-40huadaHAWKER霍克锂电池EV48-40huadaHAWKER霍克锂电池EV48-40huadaHAWKER霍克锂电池EV48-40huadaHAWKER霍克锂电池EV48-40huadaHAWKER霍克锂电池EV48-40huadaHAWKER霍克锂电池EV48-40


霍克动力电源有限公司霍克动力电源早在1891年就开始生产各种铅酸蓄电池,是世界上较早的电池制造商之一。经过逾百年的发展,其有竞争力的电池技术。公司耗巨资建立的“测试计量实验室”是产品的保障。该实验室经国家测量鉴定中心授权,可对任何品牌的蓄电池进行测试,其证书得到国际承认。英国BS标准中关于电池部分是由该实验室参与制定的。本世纪七十年代,随着世界通讯技术的不断革新和发展,对通讯后备电源的要求不断提高,在英国电信的配合下,霍克动力电源于1982年用其专利注册的.(RECOMBINATION ELECTROLYTE)再化合技术成功地生产了密封的阀控式密封铅酸蓄电池并投向市场。随着十几年来技术的不断改进与提高,其产品华达霍克系列(HUADA HAWKER)阀控电池已在欧洲、美洲、亚洲、澳大利亚等地的通讯、电力、石油化工、海洋工业、太阳能、国防、航空及其他专业场所得到了广泛应用。


霍克动力电源符合严格的标准。公司的质量管理获得ISO9001标准认证。运作系统遵从 2(MANUFACTURE RESOUCE PROGRAM)包括从接到定单至发货的所有生产过程。


霍克动力电源是电池生产商及供应商,并在电池技术行列中成为,使它的全球化能力得到加强。在全球,它有20多家公司,年销售额超过37亿美圆。动力电源应用主要包括物料运输、铁路及采矿等行业的OEM制造商和售后零配件市场;后备电源应用主要包括通信、不间断电源、电力、安防、工业设备、交换机及电子设备等;产品主要包括锂电池、充电机、充电站、零配件及系统安装维护服务。


霍克动力电源通过全体员工努力和行业合作及伙伴供应商合作等途径,致力于提供给客户优秀的产品、服务。超越客户期望和提供高质量的产品与服务是霍克电池集团的经营理念,在这个理念的驱动下,霍克动力电源以协助客户完成目标为宗旨,不断提高和完善自身的产品与服务。


今天,我们的后备电源子品牌主要为HAWKERPZS、HUADA HAWKER、此外,我们也生产相关的AGV产品,如充电站、锂电池、电子电源设备、机柜和各种蓄电池配件等。霍克动力电源提供各种规格、技术、容量、配置的蓄电池产品,能满足不同领域客户多样化的应用需求。


霍克动力电源有限公司 (HAWKER POWER SUPPLY CO,LTD)


HAWKER|霍克锂电池


产品名称:HAWKER|霍克锂电池EV系列

编号:105131-114

型号:105131-114

简单介绍:

HAWKER|霍克EV系列锂电池是专用于移动式机械快速充电的电池组,采用先进水平的磷酸铁锂(LiFePO4)材料电芯。具有高能量密度、超长的循环寿命、热稳定性强、支持大功率充放电的优良特性,是新一代稳定、安全、可靠的绿色动力电源。



Introduction

Hawker AGV SAFE EV series of power battery, is the international advanced level of lithium iron phosphate (LiFePO4) power battery system. With high energy density, long cycle life, excellent charge and discharge performance, good temperature performance, is a new generation of high security and high reliability of the green power supply.

This series of batteries is the use of the latest development of the battery management system (BMS), specifically for mobile mechanical equipment, online charging and wireless charging and design and production of power batteries, with advanced battery self-management, communication, alarm and short-term fast charge Complete function.



Product Features

● Excellent charge and discharge overvoltage and undervoltage protection

● provide analog output AO, SOC analog output 0 ~ 5V, user-friendly power monitoring

Note: SOC can only be used as a reference, can not be used as a decision.

● Provides a highly efficient passive equalization system

● Charge / discharge are all with short circuit insurance

● Panel LED power, system status display

● Rich interface, through the digital IO and 485 interface to achieve information exchange

● professional industrial design and material ion, sustainable work in the harsh industrial environment

● support high-power charge and discharge, to meet the needs of a variety of different industrial conditions

● wide temperature working environment conditions, -20 degrees -60 degrees

● small size



Dimensions specifications


TypesBattery size

Long*wide*high(mm)Charge continuous currentDischarge continuous currentEV24-40315*237*165mm80A20AEV24-60315*240*215mm

320*237*188mm

460*220*150mm120A30AEV24-80355*330*215mm160A40AEV24-100355*330*215mm200A50AEV24-120400*275*245mm180A60AEV24-200550*210*425mm200A100AEV48-30345*238*200mm60A30AEV48-60590*240*240mm120A30AEV48-80585*345*230mm160A40AEV48-100585*345*230mm200A50AEV48-160605*435*255mm160A80AEV48-200615*650*250mm160A100AEV48-250605*290*480mm200A125A


Performance specificationsprojectFeaturesOvervoltage protection3.7V (single string)Undervoltage protection2.8V (single string)Charging parametersMaximum 2C lasts for 10 minutes, 1C continuesDischarge parametersUp to 1C continuousCharge and discharge port formCharge and dischargefuseHaveRS-485 communicationHaveAnalog output AOHaveConfigurable DO outputHavePower LED displayHaveMaster switchHaveOperating temperature-20℃~60℃Storage temperature-20℃~70℃Working humidityRelative humidity of 10% to 80%, no condensationcooling systemPassive natural coolingCharger requirementsLithium iron phosphate battery chargerBattery shell colorToyota White (customizable)
